Frame | Alpha Gold Aluminium, tapered head tube, internal derailleur and dropper post routing, rack and kickstand mount, Boost141, 5 mm QR |
---|---|
*Fork | Size: XS SR Suntour XCM 32, coil spring, preload, lockout, 47 mm offset, Boost110, 15 mm thru axle, 100 mm travel |
Size: S, M, M/L, L, XL, XXL SR Suntour XCM 32, coil spring, preload, lockout, 47 mm offset, Boost110, 15 mm thru axle, 120 mm travel |
|
Max compatible fork travel | 120mm (XS: 100mm) |
Hub front | Formula DC-511, 6-bolt, Boost110, 15 mm thru axle |
---|---|
Hub rear | Formula DC-2241, alloy, 6-bolt, Shimano 8/9/10 freehub, Boost141, 5 mm QR |
Rim | Alex MD35, tubeless compatible, 32-hole, 35 mm width, Presta valve |
Spokes | 14 g stainless steel |
Tyre | Kenda Havok, wire bead, 30 tpi, 27.5x2.80" |
Rim strip | Bontrager TLR |
Max tyre size | Frame: 27.5x2.80" or 29x2.40" Fork: See manufacturer |
Shifter | Shimano Deore M4100, 10 speed |
---|---|
Rear derailleur | Shimano Deore M5120, long cage |
*Crank | Size: XS, S FSA Alpha Drive, 28T steel ring, Boost, 170 mm length |
Size: M, M/L, L, XL, XXL FSA Alpha Drive, 28T steel ring, Boost, 175 mm length |
|
Bottom bracket | Shimano 7420ST, 73 mm, threaded cartridge, 124.5 mm spindle |
Cassette | Shimano Deore M4100, 11-46, 10-speed |
Chain | KMC X10, 10-speed |
Pedal | VP-536 nylon platform |
Max. chainring size | 32T |
Saddle | Bontrager Arvada, steel rails, 138 mm width |
---|---|
*Seatpost | Size: XS, S, M TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length |
Size: M/L, L, XL, XXL TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length |
|
*Handlebar | Size: XS Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width |
Size: S, M, M/L, L, XL, XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
Grips | Bontrager XR Trail Comp, nylon lock-on |
*Stem | Size: XS, S, M Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length |
Size: M/L, L, XL, XXL Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
|
Head set | Semi-integrated, cartridge, 1-1/8" top, 1.5" bottom |
Brake | Shimano MT200 hydraulic disc |
*Brake rotor | Size: XS, S, M, M/L, L, XL, XXL Shimano RT26, 6-bolt,160 mm |
Size: M, M/L, L, XL, XXL Shimano RT26, 6-bolt,180 mm |
Weight | M – 33.97 lb / 15.41 kg |
---|---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
Joan Doe,
store owner
Basic Labour / Fitting Charge – €7
Bar tape fitting
Cutting Handlebars to size
Fitting Handlebars (road handlebars €20 because of time consumption)
Fitting baskets, mudguards and car racks
Service 1 – €45 (€25 non geared bikes)
Frame and forks checked for damage
Headset and steering bolts checked and adjusted
Bottom Bracket and crankset checked and externally adjusted
Hubs checked and externally adjusted
Wheel true checked (truing is €15-€25 extra + €1 / 50c per spoke)
Brakes checked and sdjusted
Gears checked and adjusted
Drive greased if necessary
Tyres checked for wear and pumped to correct pressure
Safety Check of all fittings
